Eaton BAB2030 BAB, 2 Pole, 30 Amp, Bolt-On Circuit Breaker, 240 Volt
Eaton BAB2030 BAB, 2 Pole, 30 Amp, Bolt-On Circuit Breaker, 240 Volt
Eaton | ID: 4034
Manufacturer Part Number: BAB2030
Technical Documents
Specifications
| Description | EATON BAB2030 30A 2P SW NEUT B |
| Amperage Rating | 30 A |
| Voltage Rating | 240V |
| Application | Datacentres, IT Space, CI and Hyper Converged, Generation - Conventional Energy, Renewable Energy, Alternative Energy, Marine Vessels and Equipment, Residential Buildings and Facilities and Industrial Applications |
| Catalog Description (MFR) | Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,Switching neutral,30 A,10 kAIC,Two-pole,120/240 V,Non-Interchangeable,Q7,BAB,Ring or spade lug terminals |
| Catalog_Notes | HACR rated |
| Certifications | CSA Certified, UL Listed |
| Dimensions | 3.9 x 2.2 x 4.8 |
| Frequency Rating | 50/60 HZ |
| Interrupt Rating | 10 kA |
| Marketing Message (MFR) | Eaton’s bolt-on miniature circuit breakers (Quicklag) provide superior protection in panelboards, and offer easy installation. They are also switching duty rated for 120 VAC fluorescent light applications, and UL 489 listed. All products 15–100A are HACR rated. Select from one-, two-, or three-pole designs. |
| Mounting Type | Bolt-On |
| Number Of Poles | 2 Pole |
| Phase | 1 |
| Product Feature | Compact designs available to minimize panel size., Field-mountable accessories make installation and on-site custom configuration easy., Flexible power feed connection (wire size and position) offers product uniformity as well as ease of installation. |
| Product Name | Eaton BAB thermal magnetic circuit breaker |
| Product Type | Thermal magnetic circuit breakers |
| Special Features | Switching neutral |
| Standard | CSA Certified,UL Listed |
| Substitutes | 30035 |
| Trip Type | Thermal Magnetic |
| Type | Type BAB |
| Wire Size | 14 to 4 AWG |
