Eaton CCV2150X Type CCV Tenant Main Circuit Breaker, 120/240 V AC, 150 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Eaton CCV2150X Type CCV Tenant Main Circuit Breaker, 120/240 V AC, 150 A, 10 kA Interrupt, 2 Poles, Thermal Magnetic Trip
Eaton | ID: 453224
Manufacturer Part Number: CCV2150X
Technical Documents
Specifications
| Description | EATON CCV2150X EATON CCV TENANTMAIN BREAKER |
| Amperage Rating | 150 A |
| Voltage Rating | 120/240V |
| Application | Circuit Protection and Type ECC Unit Enclosure Applications |
| Dimensions | 8 IN L x 4-1/2 IN W x 5-1/2 IN H |
| Enclosure Type | NEMA 1/3R |
| Interrupt Rating | 10 kA |
| Number Of Poles | 2 Pole |
| Phase | 1 Phase |
| Trip Type | Thermal Magnetic |
| Wire Size | 2/0 AWG to 300 kcmil Copper/Aluminum |
