EATON GHB1060 C Series Type GHB Molded Case Circuit Breaker, 277 VAC/125 VDC, 60 A, 14 kAIC at 277 VAC Interrupt, 1 Poles, Fixed Thermal/Fixed Magnetic Trip

Specifications

Description	EATON GHB1060 60A GHB 1P BKR
Amperage Rating	60 A
Application	Panelboard, Switchboard, Motor Control Center, Busway, Electrical Assemblies and OEMs Applications
Catalog Description (MFR)	Eaton Series C complete molded case circuit breaker, G-frame, GHB, Complete breaker, Fixed thermal, Fixed magnetic trip type, Single-pole, 60 A, 277 Vac, 125 Vdc, 14 kAIC at 277 Vac, 50/60 Hz
Current Rating	60 A
Dimensions	2.63 x 1 x 4
Frame	G
Frequency Rating	50/60 HZ
Interrupt Rating	14 kAIC at 277 Vac
Marketing Message (MFR)	Experience the superior quality of the Eaton Series C Molded Case Circuit Breaker. The Series C circuit breaker is ideal for panelboards, switchboards, motor control centers, and busway applications. Choose from a premier selection of trip units including thermal magnetic, electronic, and magnetic only switches. Available for systems up to 600 VAC or 250 VDC with current ratings up to 800A.
Mounting Type	Bolt-On
Number Of Poles	1 Pole
Standard	UL Listed,Federal Specifications Classification W-C375B
Trip Type	Thermal Magnetic
Type	Type GHB
Wire Size	10 to 1/0 AWG
