EATON GHCGFEP1020 C Series Type GHCG Molded Case Ground Fault Circuit Protector, 277/480Y VAC, 125/250 VDC, 20 A, 14 kA Interrupt, 1 Pole, Fixed Thermal/Fixed Magnetic/Non-Interchangeable Trip
EATON GHCGFEP1020 C Series Type GHCG Molded Case Ground Fault Circuit Protector, 277/480Y VAC, 125/250 VDC, 20 A, 14 kA Interrupt, 1 Pole, Fixed Thermal/Fixed Magnetic/Non-Interchangeable Trip
Eaton | ID: 205091
Manufacturer Part Number: GHCGFEP1020
Specifications
| Description | EATON GHCGFEP1020 GHC GF EQUIPPROTECTOR 30MA 1P LUG LUG |
| Amperage Rating | 20 A |
| Application | Industrial, Electrical Assemblies, Panels and OEMs Applications |
| Catalog Description (MFR) | Eaton Series C complete molded case circuit breaker, G-frame, GHC, Complete breaker, Fixed thermal, fixed magnetic trip type, Single-pole, 20A, 480Y/277 Vac, 125/250 Vdc, 14 kAIC at 277 Vac, 50/60 Hz |
| Current Rating | 20 A |
| Dimensions | 2.63 x 1 x 4.88 |
| Frame | G |
| Frequency Rating | 50/60 HZ |
| Interrupt Rating | 14 kA |
| Marketing Message (MFR) | Experience the superior quality of the Eaton Series C Molded Case Circuit Breaker. The Series C circuit breaker is ideal for panelboards, switchboards, motor control centers, and busway applications. Choose from a premier selection of trip units including thermal magnetic, electronic, and magnetic only switches. Available for systems up to 600 VAC or 250 VDC with current ratings up to 800A. |
| Mounting Type | Surface |
| Number Of Phases | 1 |
| Number Of Poles | 1 Pole |
| Phase | 1 |
| Standard | UL 489 |
| Trip Range | 30 mA |
| Trip Type | Thermal Magnetic |
| Type | Type GHCG Molded Case |
