EATON QuickLag QB1030GF Type ETN01/QBGFT Ground Fault Circuit Breaker, 120/240 V AC, 30 A, 10 kA Interrupt, 1 Poles, Thermal Magnetic Trip
EATON QuickLag QB1030GF Type ETN01/QBGFT Ground Fault Circuit Breaker, 120/240 V AC, 30 A, 10 kA Interrupt, 1 Poles, Thermal Magnetic Trip
Eaton | ID: 450880
Manufacturer Part Number: QB1030GF
Technical Documents
Specifications
| Description | EATON QB1030GF BOLT-ON GFCI, 1POLE, 10KAIC, 35A*** REPLACES QBGFT1030 *** |
| Amperage Rating | 30 A |
| Voltage Rating | 120/240V |
| Application | Conventional Energy, Renewable Energy and Alternative Energy Generation, Datacenters, IT Space - CI, Hyper Converged, Marine Vessels and Equipment Applications |
| Dimensions | 4 IN L x 3-1/2 IN W x 1 IN H |
| Interrupt Rating | 10 kA |
| Marketing Message (MFR) | Eaton has a wide selection of UL rated miniature circuit breakers for loadcenters, fuseboxes, or similar devices. Each pole provides steel frame calibration and arc chutes with 5 - 100A continuous in one-, two-, and three-pole designs. A full-range of accessories expand customization options, including various mounting and ring tung termination options. |
| Mounting Type | Bolt On |
| Number Of Poles | 1 Pole |
| Standard | UL 489,Contact Manufacturer |
| Trip Range | 30 A |
| Trip Type | Thermal Magnetic |
| Wire Size | 14 to 4 AWG |
