GE TEY2100 Compact Lighting Panel Circuit Breaker, 120/240/277 V AC, 100 A, 14/65 kA Interrupt, 2 Poles, Thermal Magnetic Trip
GE TEY2100 Compact Lighting Panel Circuit Breaker, 120/240/277 V AC, 100 A, 14/65 kA Interrupt, 2 Poles, Thermal Magnetic Trip
GE | ID: 122831
Manufacturer Part Number: TEY2100
Specifications
| Description | ABB TEY2100 2P 480V 100A CB |
| Amperage Rating | 100 A |
| Voltage Rating | 480V |
| Actuator | Pivot/Toggle Handle |
| Application | Switchboards, Motor Control Centers, Lighting, Power and Customized Control Panelboards and Electrical Distribution Applications |
| Dimensions | 2 IN W x 3-1/16 IN D x 5-1/4 IN H |
| Frame | TEY |
| Frequency Rating | 50/60 HZ |
| Includes | Integral Copper/Aluminum Load Lug |
| Interrupt Rating | 14/65 kA |
| Material | Plastic |
| Mounting Type | Bolted-On |
| Number Of Poles | 2 Pole |
| Phase | 1 |
| Trip Type | Thermal Magnetic |
| Type | Compact |
| Wire Size | 14 to 8 AWG, 12 to 8 AWG |
