GE TEY260 Compact Lighting Panel Circuit Breaker With Copper/Aluminum Load Lug, 120/240/277 V AC, 60 A, 65/14 kA Interrupt, 2 Poles, Thermal Magnetic Trip
GE TEY260 Compact Lighting Panel Circuit Breaker With Copper/Aluminum Load Lug, 120/240/277 V AC, 60 A, 65/14 kA Interrupt, 2 Poles, Thermal Magnetic Trip
GE | ID: 43199
Manufacturer Part Number: TEY260
Specifications
| Description | ABB TEY260 2P 480V 60A CB |
| Amperage Rating | 60 A |
| Voltage Rating | 277/480V |
| Actuator | Pivot/Toggle Handle |
| Application | Switchboards, Motor Control Centers, Lighting, Power and Customized Control Panelboards and Electrical Distribution Applications |
| Dimensions | 5-1/4 IN H x 2 IN W x 3-1/16 IN D |
| Frame | TEY |
| Frequency Rating | 50/60 HZ |
| Interrupt Rating | 65/14 kA |
| Material | Plastic |
| Mounting Type | Bolted-On |
| Number Of Poles | 2 Pole |
| Phase | 1 |
| Trip Type | Thermal Magnetic |
| Type | Compact |
| Wire Size | 14 to 8 AWG, 12 to 8 AWG |
