ILSCO SureCrimp CLND-750-12-134 CLND 2-Hole Lug Compression Connector, 500 to 750 kcmil Flex Copper Conductor, Die Code: ILD-106, 1/2 in Stud, Tin Plated Copper
ILSCO SureCrimp CLND-750-12-134 CLND 2-Hole Lug Compression Connector, 500 to 750 kcmil Flex Copper Conductor, Die Code: ILD-106, 1/2 in Stud, Tin Plated Copper
ILSCO | ID: 103258
Manufacturer Part Number: CLND-750-12-134
Specifications
| Description | ILSCO CLND-750-12-134 2HOLE LUG |
| Application | Terminating Connector, Grounding and Bonding Applications |
| Catalog Description (MFR) | Surecrimp Copper Compression Lug, Conductor Size 750, 2 Holes, 1/2in Bolt Size, 1-3/4in Hole Spacing, Long Barrel, No Sight Window, Tin Plated, UL, CSA |
| Certifications | ECCN, PROP65 |
| Color | Black |
| Dimensions | 1.901 IN W |
| Material | Tin Plated Copper |
| Mounting Holes | 0.562 in |
| Standard | NEBS Level 3, UL 453G, UL 486A-486B File No. E6207, UL 467, CSA File No. LR29601, ECCN EAR99 |
| Stud Size | 1/2 IN |
| Tongue Size | 3 in L x 1.901 in W x 0.282 in THK |
| Type | 2-Hole |
