Leviton D2GF2-KW Duplex Feed Through Self-Test Tamper Resistant GFCI Receptacle/Outlet, 125 VAC, 20 A, 2 Poles, 3 Wires, White
Leviton D2GF2-KW Duplex Feed Through Self-Test Tamper Resistant GFCI Receptacle/Outlet, 125 VAC, 20 A, 2 Poles, 3 Wires, White
LEVITON | ID: 595950
Manufacturer Part Number: D2GF2-KW
Technical Documents
Specifications
| Description | LEV D2GF2-KW 20A WI-FI AUDIBLEGFCI WH |
| Amperage Rating | 20 A |
| Voltage Rating | 125VAC |
| Application | Indoor, Ideal for refrigerators, sump pumps and other appliances |
| Catalog Description (MFR) | SMART GFCI OUTLET, TAMPER-RESISTANT, WI-FI CERTIFIED, WORKS WITH MY LEVITON APP; 20A OUTLET, 20A FEED-THROUGH, 125V, 60HZ; PACKED 1/BOX, 4/CARTON |
| Color | White |
| Dimensions | 4.19 IN H x 1.68 IN W x 1.69 IN D |
| Frequency Rating | 60 Hz |
| Grade | Residential/Commercial Specification |
| Horsepower | 1 HP |
| Includes | Wallplate |
| Marketing Message (MFR) | Leviton®, D2GF2-KW, GFCI Receptacle/Outlet, Duplex Feed Through Self-Test Tamper Resistant, 125 VAC, 20 A, 1 hp, 60 Hz Frequency, 2 Pole, 3 Wires, NEMA 5-20R NEMA Rating, Residential/Commercial Specification Grade, -35 to 66 deg C, Back/Side Terminal, Polycarbonate, White, 4.19 in H x 1.68 in W x 1.69 in D Dimensions |
| Material | Polycarbonate |
| NEMA Rating | 5-20R |
| Number Of Poles | 2 Pole |
| Number Of Wires | 3 |
| Standard | cULus Listed, UL File E48380/943 Class A/498 Listed, NOM Certified, Federal Specification W-C-596G |
| Type | Duplex Feed Through Self-Test Tamper Resistant |
